- [S-FD EI120 L210] FUSIBLE LINK INSULATED FIRE DAMPER
![[S-FD EI120 L210] FUSIBLE LINK INSULATED FIRE DAMPER](https://starduct.vn/storage/2023/10/11/VAN FD CẦU CHÌ LÒ XO XOẮN EI60 L210.png (2).png)
![[S-FD EI120 L210] FUSIBLE LINK INSULATED FIRE DAMPER](https://starduct.vn/storage/2023/10/11/VAN FD CẦU CHÌ LÒ XO XOẮN EI60 L210.png (1).png)
![[S-FD EI120 L210] FUSIBLE LINK INSULATED FIRE DAMPER](https://starduct.vn/storage/2023/10/11/HỆ VAN VÀ ỐNG EI STARDUCT 3.png)
[S-FD EI120 L210] FUSIBLE LINK INSULATED FIRE DAMPER
Product codeS-FSD L210
Order codeS-FD L210 (W x H)
MaterialMaterail Frame: L210mm, 1 GL steel, 1.15mm + 2 layers MgSO4 thickness 10mm, Density 950kg/m3 + 1 layer MGO t=38mm, density 380kg/m3. Damper blade: 1 GL steel, t=1.5mm + 2 layers MgSO4, t=10mm, density 950kg/m3 + 2 layers ceramic wool, t= 20mm, density 220kg/m3. Blade stop: GL steel, t= 1.15mm Shaft: Steel CT45 CNC, D20. Bearing: Stainless steel sleeve SS304 Frame sealant : Hilti Cp606 Blade sealant : Hilti FS one Max
ApplicationType: S-FSD models are symmetric dampers for installation in walls in fire zones and have fire resistance rating of 120/90/60/45/30 minutes (EI).
Related products
![[S-FD EI120 L210] FUSIBLE LINK INSULATED FIRE DAMPER](https://starduct.vn/storage/2024/06/08/Van FD EI120.jpg)
[S-FD EI120 L210] FUSIBLE LINK INSULATED FIRE DAMPER
Product code:
S-FSD L210
S-FSD L210
Application:
Type: S-FSD models are symmetric dampers for installation in walls in fire zones and have fire resistance rating of 120/90/60/45/30 minutes (EI).
Type: S-FSD models are symmetric dampers for installation in walls in fire zones and have fire resistance rating of 120/90/60/45/30 minutes (EI).
FUSIBLE LINK FIRE DAMPER FSS EI120 L210
Product code:
S-FSS-L210
S-FSS-L210
Application:
Type: S-FSD models are symmetric dampers for installation in walls in fire zones and have fire resistance rating of 120/90/60/45/30 minutes (EI).
Type: S-FSD models are symmetric dampers for installation in walls in fire zones and have fire resistance rating of 120/90/60/45/30 minutes (EI).
Insulated Motorized Fire Damper (ei)
Product code:
S-MFSD-2480(W)x1680(H)x600(L)
S-MFSD-2480(W)x1680(H)x600(L)
Application:
Type: S-MFSD models are symmetric dampers for installation in walls of the two fire zones and have fire resistance rating of 120/90/60/45/30 minutes (EI).
Type: S-MFSD models are symmetric dampers for installation in walls of the two fire zones and have fire resistance rating of 120/90/60/45/30 minutes (EI).
FIRE DAMPER MOTORIZED (E) (UNINSULATED)
Product code:
S-FD-M-1200(W)x1200(H)x210(L)
S-FD-M-1200(W)x1200(H)x210(L)
Application:
QCVN 06:2021/BXD
QCVN 06:2021/BXD
[S-FD EI120 L210] FUSIBLE LINK INSULATED FIRE DAMPER
Product code:
S-FSD L210
S-FSD L210
Application:
Type: S-FSD models are symmetric dampers for installation in walls in fire zones and have fire resistance rating of 120/90/60/45/30 minutes (EI).
Type: S-FSD models are symmetric dampers for installation in walls in fire zones and have fire resistance rating of 120/90/60/45/30 minutes (EI).
FUSIBLE LINK FIRE DAMPER FSS EI120 L210
Product code:
S-FSS-L210
S-FSS-L210
Application:
Type: S-FSD models are symmetric dampers for installation in walls in fire zones and have fire resistance rating of 120/90/60/45/30 minutes (EI).
Type: S-FSD models are symmetric dampers for installation in walls in fire zones and have fire resistance rating of 120/90/60/45/30 minutes (EI).
Insulated Motorized Fire Damper (ei)
Product code:
S-MFSD-2480(W)x1680(H)x600(L)
S-MFSD-2480(W)x1680(H)x600(L)
Application:
Type: S-MFSD models are symmetric dampers for installation in walls of the two fire zones and have fire resistance rating of 120/90/60/45/30 minutes (EI).
Type: S-MFSD models are symmetric dampers for installation in walls of the two fire zones and have fire resistance rating of 120/90/60/45/30 minutes (EI).
FIRE DAMPER MOTORIZED (E) (UNINSULATED)
Product code:
S-FD-M-1200(W)x1200(H)x210(L)
S-FD-M-1200(W)x1200(H)x210(L)
Application:
QCVN 06:2021/BXD
QCVN 06:2021/BXD
FIRE DAMPER FUSE - RETURN SPRING (UNINSULATED)
Product code:
S-FD-FS-1200(W)x1200(H)x210(L)
S-FD-FS-1200(W)x1200(H)x210(L)
Application:
QCVN 06:2021/BXD
QCVN 06:2021/BXD
INSULATED FLEXIBLE DUCT
Product code:
STI D100 ~ D600
STI D100 ~ D600
Application:
Cấp khí lạnh
Cấp khí lạnh
WALL MOUNTED MOTORISED FIRE DAMPER EI120 L210
Product code:
S-MFSD-L210
S-MFSD-L210
Application:
Type: S-MFSD models are symmetric dampers for installation in walls in fire zones and have fire resistance rating of 120/90/60/45/30 minutes (EI).
Type: S-MFSD models are symmetric dampers for installation in walls in fire zones and have fire resistance rating of 120/90/60/45/30 minutes (EI).
Fresh Air Fire Damper
Product code:
SAFD
SAFD
Application:
Cấp bù khí cho hệ TAHK, Chống tụ khói
Cấp bù khí cho hệ TAHK, Chống tụ khói
